We Provide a Large Selection of 904L Stainless Steel Forged Fittings Available in 904L Stainless Steel High Pressure Forged Fittings in Best Quality. We Keep Bulk Stock of ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 SS 904L Socket weld Fittings, Threaded Fittings for quick delivery to Our Clients.Rishabh Steel Industries. is a distributor, supplier and exporter of Stainless Steel 904L Forged Fittings. It is an innovative and creative company that has received its ISO certification. This means that it complies with all the national and international standards that have been set up. Stainless Steel 904L is non-stabilized and austenitic with low carbon content. Copper is added to this stainless steel alloy in order to improve its resistance to strong reducing acids like sulphuric acid. This grade of stainless steel is resistant to crevice corrosion and stress corrosion cracking.
Stainless Steel UNS N08904 Forged Pipe Elbows have an essential feature which is weldability and excellent formability. It is also non-magnetic in nature. Stainless Steel DIN 1.4539 Socketweld Caps are used to seal the ends of a pipe. These fittings have great oxidation and heat resistance. Stainless Steel 904L Forged Pipe Nipple are used in several application industries such as gas scrubbing plants, seawater cooling devices and for the wiring in electrostatic precipitators. The prices that are charged are competitive yet reasonable. This ensures that these 904L Stainless Steel Forged Fittings are available to all criteria of clients. Also We offer wide range of Stainless Steel ASTM B649 904L Forged Fittings such as SS 904L Forged Elbow, SS 904L Forged Equal Tee, SS 904L Forged Coupling, SS 904L Forged Pipe Cap, SS 904L Forged Union, SS 904L Forged Bushing, SS 904L Forged Plug, SS 904L Forged Pipe Nipple, SS 904L Forged Street Elbow. Manufacturer and Supplier of SS 904L Threaded Elbow, SS 904L Forged Fittings. Huge stock of standard Stainless Steel 904L Forged Threaded Fitting is in ready stock.
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR | JIS | BS | KS |
| SS 904L | 1.4539 | N08904 | X1NiCrMoCu25-20-5 | Z2 NCDU 25-20 | SUS 904L | 904S13 | STS 317J5L |
| Specifications | ASTM A182 & ASME SA182 |
|---|---|
| Stainless Steel Forged Pipe Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| ASTM A182 F904L Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Werkstoff No 1.4539 SS 904L Thread Fittings | NPT , BSPT, BSPP |
| ASME SA182M F904L FittingsType | DN15-DN1200 |
| End | Threaded, Welding, JIC |
| Pressure Rating | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings |
| UNS N08904 Forged Steel Fitting Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Manufacturers of A182 F904L Forged Fittings |
|
| Origin | West Europe / Japan / Indian / USA / Korean |
| Industrial Applications for ASME SA182M SS 904L Pipe Fittings |
|
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Specifications
ASTM A182 F904L
Grades of Stainless Steel 904L Forged Elbow
Size: 1/8" to 2" 45 degree
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Grades of SS Forged 904L 90 Degree Elbow
Size: 1 inch,1/4 inch,2 inch,3/4 inch
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Grades of SS Forged 180 Degree Elbow
Size: 1/2"NB to 48"NB
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: ½NB to 24″NB
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: As Per Customer Requirement
Surface Finish: Mill Finished
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: 2 inch,3 inch,1 inch,1/2 inch,>3 inch,3/4 inch
Surface Finish: Polished
Pressure: 300 psi
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: 2 inch,3 inch,1 inch,1/2 inch,>3 inch,3/4 inch
Pressure: 3000#, 6000#, 9000#
Specifications
Dimension : As Per ASME B16.9
Thickness : SCH: 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS
Size: 1/2"NB TO 48"NB IN
Pressure: 3000#, 6000#, 9000#
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: 1/8 TO 4"
Pressure Class : 3000LBS, 6000LBS, 9000LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size: Customized
Pressure Class : 3000LBS, 6000LBS, 9000LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size : 1/2 TO 36
Standards : ASME / ANSI - B 16.9, ASTM A182 - ASME SA182, ASME B16.9, ASME B16.25, MSS SP-43.
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size : 1 inch,1/2 inch,3/4 inch
Standards : ASME / ANSI - B 16.9, ASTM A182 - ASME SA182, ASME B16.9, ASME B16.25, MSS SP-43.
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size : 1/8" NB TO 48" NB (Seamless & Welded)
Standards :ASME, ANSI, API, JIS, DIN
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : Sch.5S- Sch.XXS
Size : 1/2"NB TO 4"NB IN
Standards :ASME, ANSI, API, JIS, DIN
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness : SCH5. SCH10, SCH20, SCH30, SCH40, STD
Size : Customized
Nominal Size : 2 inch,3/4 inch,1 inch,1/2 inch
Standards :ASME, ANSI, API, JIS, DIN
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness, Schedule : SCH5. SCH10, SCH20, SCH30, SCH40, STD,
Size : 1/2"NB TO 24"NB
Standards :ASME, ANSI, API, JIS, DIN
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness, Schedule : SCH5. SCH10, SCH20, SCH30, SCH40, STD,
Size : 1/2"NB TO 24"NB
Standards : GB / ASTM / ASME / DIN / JIS
Outside Diameter :- 1/2" - 48" NB
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
Specifications
ASTM A182 F904L
Dimension : As Per ASME B16.9
Thickness, Schedule : SCH5. SCH10, SCH20, SCH30, SCH40, STD,
Size : Customized
Standards : GB / ASTM / ASME / DIN / JIS
Usage: Industrial,Domestic
Pressure Class : 3000 LBS, 6000 LBS, 9000 LBS
150 lb stainless steel cast fittings are manufactured through the process of heating metal to a molten/liquid state and pouring the metal into a vessel creating the desired shape. The fitting product is then created to specification through a finishing process. Cast products are sometimes larger in size because it is an easier and more affordable process compared to forging, which creates a product from a solid state. Casting also has advantages with custom alloys where these metals can be added in the molten stage.
| Fitting Schedule/Class | Pipe Size - Pipe Fitting | Fitting Connection Type | Pipe Fitting Material | Max. Pressure |
|---|---|---|---|---|
| Class 150 | 1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1/2" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 1/2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 3/4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 3/4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 3/4" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 3/4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 3/4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 1" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/4" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 1-1/4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/2" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 1-1/2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 1-1/2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 2" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 2-1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 2-1/2" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 2-1/2" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 2-1/2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 2-1/2" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 3" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 3" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 3" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 3" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 4" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 4" | Forged | Forged Stainless Steel 904L | 275 psi |
| Class 150 | 4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 4" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 6" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 6" | FNPT | Stainless Steel 904L | 150 psi |
| Class 150 | 6" | Welded | Stainless Steel 904L | 150 psi |
| Class 150 | 6" | Welded | Stainless Steel 904L | 150 psi |
| CR | Corrosion resistant grade. S through WU Classes do not apply. |
| WP-S | Seamless |
| WP-W | Welded, RT or UT all pipe starting material welds made with filler metal. All fitting manufacturer welds except as excluded in A/Sb649 paragraph 5.4.3. If UT is substituted for RT, all welds must be examined 100% for their length as required by A/Sb649 paragraph 5.6 |
| WP-WX | RT all welds with or without filler metal. |
| WP-WU | UT all welds with or without filler metal. |
| WPgrade-grade-class | Insert grades (904L-904LL) and class (S,W,WX, or WU). Applies to fittings meeting all chemical and physical requirements of both grades. |
| DN-NPT | MAJOR DIAMETER MM |
TAPPING DRILL SIZE MM |
TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
| Grade | Ni | C | Mn | Si | P | S | Cr | Mo | Cu |
| SS 904L | 23.00 – 28.00 | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 | 4.00 – 5.00 max | 1.00 – 2.00 |
| Yield Strength (0.2%Offset) | Tensile Strength | Density | Melting Point | Elongation |
| Psi – 32000 , MPa – 220 | Psi – 71000 , MPa – 490 | 7.95 g/cm3 | 1350 °C (2460 °F) | 35 % |
